功能与概况/Brief Introduction：

全重新注塞泵式膏体酱灌装线线机是公司适合市场的的需求规划设计的新专利技术。此机所采用SUS304304不锈钢注塞泵式的计量泵继续执行灌装线线，且集重新上盖、重新旋盖、电气开关自动化电气开关为一起，经济发展使用，拆迁赔偿占地面小，常见使用于制药厂、食物、化肥、石油化工、化妆师品等业的粘液包装袋，适用GMP正规规定。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

共同点/characteristic：

◆通过轴向柱塞泵式收费泵执行命令灌装线，使用种种黏稠度固态，表面粗糙性高；泵的空间结构通过快接式拆装设备，尽可能使的洗涤、杀菌消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆齿轮泵式计量检验泵连杆环材質按照职业及液滴因素的与众不同主要用硅橡胶制品，四氟氯乙烯或其它的材質，特异环境主要用陶瓷制品材質。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调整设备，变頻变频调速，手动化水平高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不装罐，半自动计数器作用。Lack of bottle filling, automatic counting function◆装量调节便利，可是一次调节全部都压力容器检验泵的充填量，也可真对其他压力容器检验泵对其进行微幅调节；方法操作简单，调节更快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装灌针头开设防滴漏问题传动装置，充填时前往瓶底装灌，慢慢上涨，可以防止气泡图片。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆机器可常用不同的外形尺寸的矿泉水瓶，设定便捷，可在间歇间内成功完成。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆服务器按GMP条件设计制作。The machine designed according to the requirements of GMP

方法运作/technic parameter：

支持水瓶座要求Size of bottles	20-1000ml（按照其特殊要求制作厂）20-1000 - ml (according to your need）
用于空瓶直径为Apply the bottle diameter	¢20-¢150mm
符合盖子规模Apply the lid specifications	¢20-¢70mm
生产制造意识 production capacity	四头灌装设备：1000-2500瓶/一小时 Four filling head: 1000-2500 bottles per hour 八头包装：2500-4000瓶/时间 Eight head filling: 2500-4000 bottles per hour 12头灌装设备：4000-6000瓶/每小时 12 head filling: 4000-6000 bottles per hour
装量随机误差The load error	±1%
旋盖及格率Screw cover percent of pass	≥99%
电压power supply	380V，50HZ
电功率power	3.0KW
汽源gas sources	0.4-0.75MPA
快慢管理speed control	变频式调速器variable speed
