应用与概况/Brief Introduction：

超声波焊接机是转变内服液破璃瓶的新的产品，切底满足了以来内服液破璃瓶的异常情况效率。此灌封机所要的塑料管瓶，不断不是须要洗瓶机、干燥机，更不是须要消毒液，能够 会灌封。设备全定时理瓶、进瓶、装灌，装灌量相对稳定可靠，无漏滴，无瓶不装灌。上盖、塑封率大约100%。此机技能先进性，质量小、开机运行相对稳定可靠、噪声源低，操作步骤维护保养、清洁便利等特征 ，全部合乎GMP标准。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本参数有低速度和高速收费站两种类型时产供您选择。Note: this model has two kinds of low speed and high-speed production for your choice.

特性 Characteristic

◆该设备适于于不同的易折瓶服食液剂量灌装生产线和粘口。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆所以电商电子器件均用于产品品牌产品品牌。All electrical components adopt famous brand◆超声波焊接机进行操作正确性以便于，无瓶不分装，测量*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折材料瓶灌封机的其主要节构与原则Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型服食液易折朔胶瓶灌封机具体理瓶器、理盖器、主齿轮传动模式、云同步带宽度送单瓶置、瓶子检漏安装、灌装线医疗医院、去除安装、热溶封医疗医院、气动系统物理手掌夹瓶医疗医院、伺服控制器同步电机宽度上瓶医疗医院与出瓶医疗医院等成分。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆POS机的使用的口服药液易折塑胶瓶、盖是一个定整洁区产出的，需要有泡脚药材准许证，所以咧瓶身与底盖经传送和"去负责"后可简单迈入灌封间。用理盖器、理瓶器的智能专向收集，剔出反方向底盖及瓶身底口朝下的瓶，使专向后的包材喂料有要求地迈入推送道路中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向就业后胶囊液易折金属瓶在传输 轨道组件第二排Directional oral liquid after folding plastic bottles in conveying rail out easily

高技术技术指标technical parameters：

型号model	NLGFY-40	NLGFY-80
装量区间The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
粘口率Hot sealing intensity	》99%
装量误差值The load error	《1.5%
磨损率damage rate	《1.0%
工率power	2KW	3KW
主机电源Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
自重 Weight	700Kg	800Kg
