适用范围与简洁/Brief Introduction：

本生育线比较合适30ML往上服用液的灌装线线线装备生育，由供瓶机、滚简洗瓶机、切线式灌装线线线装备轧（旋）盖机、垂直标贴机等装备构成的，可全半自动成功理瓶、洗瓶、灌装线线线装备、上盖、旋（轧）盖、标贴等步骤。主要应用于生物制药、面制品、化工环保的的几种流体废料的灌装线线线装备联合生育。本生育线全部达到GMP追求。This production line is suitable for more than 30 ml of oral liquid filling production, by for bottle filling machine, roller bottle washing machine, straight-line rolling (spin) cover machine, vertical labeling machine and other equipment, can finish automatically unscramble bottle, bottle washing, filling and cover, cover and label (pad). Mainly used in pharmaceutical, food, chemical industry production of all kinds of liquid filling material of the linkage of. This production line in full compliance with GMP requirements.

的特点 /Characteristic：

◆表皮的材质为304不锈钢装饰管吗装饰管，罐装部件采316L不锈钢装饰管吗装饰管，符合国家GMP规程。Outer material is 304 stainless steel,and the material of filling part is 316L stainless steel, it complies with GMP regulation ◆可适应环境多规模加工。can be situable for several bottle specs.◆操作固定，躁音小，装罐准确 。Stable running,low noise,precise filling.◆破瓶率低，半成品合格品率高，高能耗少。low bottle breakage ratio,high qualified product ratio,low energy consumption.◆整件产出线可单人调控和加盟调控。The whole line can single machine control or interlock control.

技能性能参数/Main Technical Parameters：

采用的规格Filling Volume	30-150ML
罐装头数Productivity	中速4头   𒁏;           绕城🏅高速8头 4 at low speed       ✤;      high speed 8
研发意识	减速30-50瓶/分     高速路70-100瓶/分 30-50bottles/min  70-100bottles/min
灌装设备要求Filling Precision	≤±1%
旋盖率Capping Rate	≥99%
电压Power Supply	220V/50Hz
电机功率Power Supply	2.5kw
生产的线总长Dimension	7500*1000*1700MM
